Technical Data

Temperature : -35ᴼC to +105ᴼC
Speed : ≤ 0.5 m/s
Pressure : ≤ 400 bar
Media : Hydraulic oils (mineral oil-based)

Material

Profile Seal : NBR
Back-up ring : polyester elastomer
Guide ring : POM
Hardness : 93±2 Shore A

Advantages

Good sealing effect, also suitable for holding cylinders
Insensibility against shock loads and pressure peaks
Capable of installation in closed grooves of reduced machining costs
Easy installation
