Technical Data

Temperature : -35ᴼC to +100ᴼC
Speed : ≤ 0.5 m/s
Pressure : ≤ 400 bar
Media : Hydraulic oils (mineral oil-based)

Material

Material : PU/Back-up ring POM
Hardness : 93±2 Shore A

Advantages

Unusually high wear resistance
Insensibility against shock loads and pressure peaks
Low compression set
Increased sealing performance a zero pressure
Easy installation
