Technical Data

Temperature : With NBR : -35ᴼC to +105ᴼC ,, With FKM : -35ᴼC to +200ᴼC
Pressure : ≤ 400 bar
Speed : ≤ 5 m/s
Media : Hydraulic oils (mineral oil-based)
O-ring : NBR/FKM

Material

Material : Almost All Media

Advantages

High static and dynamic sealing effect
Low friction, High efficiency
Stick-slip free starting, no sticking
Easy installation
